Dynamode PS-2U1P Scheda Tecnica Scaricare il pdf

PS-2U1P

2 USB + 1 Parallel Port Multiprotocol Print Server

The PS-2U1P totally supports USB and Parallel printer in in your office network. It

is designed for Multi-Print Port from medium to large size LAN.

Installation can be completed in minites by using a Windows-based setup

program, WEB browser, Telnet configuration and HP Web JetAdmin management tools.

INTRODUCTION

FEATURES

Two SUB 1 1-compliant ports.Each port supports 1.5/12Mbps data transmission rate and

detects the model of the USB printer automatically.

One DB25 parallel port, supports bi-directional communication.

One 10/100Mbps N-Way UTP port, supports auto cross-over.

Operationg system support Windows 95/98/ME/2000/XP, Mac OS 8.1 or higher,

UNIX/Linux and Netware(Bindery/NDS).

Management support Telnet, Web browser and Windows-based application.

Firmware ungradable support TFTP, Web browser and Windows-based application.

Protocol support TCP/IP, IPX, NetBEUI, Apple Talk, LPR and IPP.

Supports Windows and UNIX RFC 1179( peer-to-peer)printing.

Support SNMP, HP JetAdmin and Web JetAdmin.

Support DHCP Client.

LED Indication for Power, Status, LAN, USB and Parallel.

Easy Configuration and Management.

Auto Power-On Self Test.

Reset button.

1 2

Dynamode 2

Sommario

Pagina 1

PS-2U1P2 USB + 1 Parallel Port Multiprotocol Print Server The PS-2U1P totally supports USB and Parallel printer in in your office network. It is desi

Pagina 2 - Dynamode

PRODUCT SPECIFICATIONStandardIEEE 802.3 10Base-T IEEE 802.3u 100Base-TX USB 1.1-CompliantDynamode Netware Operating System SupportFully compatible wit
